TDK Organization has extended its ultra-low clamping voltage TVS diode lineup with three modern models in the SD0201 arrangement, custom fitted for high-speed shopper hardware interfacing. These TVS diodes offer compact security for USB Type-C, HDMI, DisplayPort, and Thunderbolt associations in smartphones, portable workstations, tablets, wearables, and organizing devices.
Each component comes in a 0201 chip-scale bundle (CSP), measuring fair 0.58 x 0.28 x 0.15 mm (L x W x H) for space-constrained plans. Having working voltages of ±1 V, ±2 V, and ±3.6 V, the unused TVS diodes protect touchy circuits from electrostatic release (ESD) and temporal surges. This implies they meet IEC 61000-4-2 measures with ESD release vigor up to ±15 kV and back surge current taking care of up to 7 A, depending on the variation. Their symmetrical plan empowers bidirectional security and hence adaptable PCB steering, whereas exceptionally moo spillage streams and energetic resistance as moo as 0.16 Ω improve application-level efficiency.
The person components vary in their DC working voltage and parasitic capacitance: the SD0201SL-S1-ULC101 (requesting code B74121U1036M060) has a working voltage of ±3.6 V and a parasitic capacitance of 0.65 pF, the SD0201-S2-ULC105 (B74121U1020M060) of ±2 V and 0.7 pF, and the SD0201SL-S1-ULC104 (B74121U2010M060) of ±1 V and 0.15 pF. A LTspice demonstrate library for SEED reenactments for TVS diodes is accessible for download.
TDK’s unused ultra-low clamping voltage TVS diodes are designed to meet the challenges in nowadays and tomorrow’s customer gadgets, guaranteeing solid execution and shielding touchy electronic gadgets from harming homeless people.
